169-91-026,Switched-mode power supply unit for DIN rail / 5.0 A, TSPC 120-124, Traco Power
Datasheet
| Output voltage 1, nominal | 24 VDC |
| Output current 1 max. | 5.0 A |
| Power | 120 W |
| Efficiency | 90 % |
| Input voltage, nominal | 100 / 240 VAC |
| Phases | 1 |
| Outputs | 1 |
| Width | 46 mm |
| Depth | 110 mm |
| Height | 110 mm |
| System deviation, load | ±0.5% max. |
| System deviation, supply | ±0.5% max. |
| Residual ripple | 150 mV |
| Output voltage 1 min. | 24 VDC |
| Output voltage 1 max. | 28 VDC |
| Input voltage, AC min. | 85 VAC |
| Input voltage, AC max. | 264 VAC |
| Operating temperature min. | -25 °C |
| Operating temperature max. | +70 °C |
| Input frequency min. | 47 Hz |
| Input frequency max. | 63 Hz |
| Derating | from 60 °C |
