UC2000-30GM-E6R2-V15 -

Ultrasonic sensor, UC2000-30GM-E6R2-V15, Pepperl+Fuchs

Pepperl+Fuchs UC2000-30GM-E6R2-V15
声明：图片仅供参考，请以实物为准！
制造商产品编号：
UC2000-30GM-E6R2-V15
仓库库存编号：
137-60-751
技术数据表：
View UC2000-30GM-E6R2-V15 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

UC2000-30GM-E6R2-V15技术参数

Acquisition range 80...2000 mm
Acquisition range max. 2000 mm
Acquisition range min. 80 mm
Output 2 switch outputs
Connection Plug M12
Operating voltage 10...30 VDC
Operating temperature -25...+70 °C

UC2000-30GM-E6R2-V15产品信息

Protection rating IP 65
Dimensions M30 x 94 mm
Recording angle ca.5 °@ -3 dB

UC2000-30GM-E6R2-V15配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
Related Manufacturers: Omron Industrial Automation | Panasonic | Gems | Sick | LEM
Related Categories: Sensors | Optical Sensors | Monitoring Relays
Related Products: Current transformer ± 36 A | Current transformer ± 70 A | Current transformer ± 80 A | Current transformer ± 150 A | Level switch
电话:400-900-3095
QQ:800152669

UC2000-30GM-E6R2-V15Family Information

Series Description
  • Range up to 6 m
  • Very small blind range
  • Structural forms M30 (version 30GM) or cuboid / Varikont (version U9)
  • Measuring range can be adjusted by means of learning plug-in (30GM) resp. DIL switch (U9)
  • Integrated parameterizing interface RS232 towards alternative measuring range setting and matching with further sensor parameters by means of the software Ultra2001 (free of cost in the Internet)
  • Switch outputs PNP (E6, E2) can be freely programmed for switching point- or window operation
  • Analog output (IU) 4...20 mA or 0...10 V, rising or falling ramp as well as test window can be arranged anywhere in the capture area of the sensor
  • High resolution through 12 Bit D/A converter
  • Switching power and sensitivity can be adjusted
  • Temperature compensation
  • LED's for power-on (green) and switching status (yellow)
  • Synchronization input for multiplex or common mode operation of up to 5 ultrasonic sensors
  • Sensor head can be replaced 5 times (version U9)
  • Connection: Plug M12, 5-pole (30GM) or terminal area (U9)
  • Parameterizing software can be downloaded free of cost from the Internet under www.pepperl-fuchs.com

UC2000-30GM-E6R2-V15产地与重量

Country of origin Singapore (SG)
Manufacturer Pepperl+Fuchs
Gross weight (incl. package) 194.0 Gram
Dimensions (incl. package) 152 x 52 x 37 MM
Customs number 9031808000
UNSPSC (v5.03) 30211910
