AC 166 GBUPF/ 3 WHITE -

Socket with strain relief Pitch9.75 mm Poles 3 AC 166 G, AC 166 GBUPF/ 3 WHITE, Adels Contact

Adels Contact AC 166 GBUPF/ 3 WHITE
声明:图片仅供参考,请以实物为准!
制造商产品编号:
AC 166 GBUPF/ 3 WHITE
仓库库存编号:
300-68-639
技术数据表:
View AC 166 GBUPF/ 3 WHITE Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

AC 166 GBUPF/ 3 WHITE技术参数

Pitch 9.75 mm
Poles 3
Series AC 166 G
Connector Termination Spring terminal
Housing Material Polyamide (PA 66)

AC 166 GBUPF/ 3 WHITE产品信息

Manufacturer Article n° 165553
Connection principle Wire-Wire
Contact material Brass
Rated current 16 A
Rated voltage 250 V
Colour white
Test voltage 2.500 V
Cable ? 7.5...8.5 mm
Cross-section 0.5...2.5 mm2
Cross-section AWG 16...14 AWG
Protection rating IP 40 when plugged-in
Temperature range -35...100 °C
Combustibility class UL 94 V-2

AC 166 GBUPF/ 3 WHITE您可能还对以下元器件感兴趣

Related Products: Crimp socket Female 30...22 AWG | Crimp contact Female 22...18 AWG | Crimp socket Female 24...20 AWG | Crimp socket 3 A Female 26...22 AWG | PCB pin header Pitch2 mm Poles 2 Single row / straight / with shroud PH
Related Manufacturers: Molex | Phoenix Contact | TE Connectivity | Weidmüller | Würth Elektronik
Related Categories: Terminal Strips & Light Terminals | Industrial Connectors | Terminal Blocks | Special Shops
电话:400-900-3095
QQ:800152669

AC 166 GBUPF/ 3 WHITEFamily Information

  • 3 or 5-pole connector consisting of plug and socket part, in white or black
  • Additional cover plate with strain relief, in white or black
  • Protected against casual contact even in the unplugged condition
  • Sealed coding profiles prevent wrong pluggings
  • Permitted as "appliance connector" EN 60320/IEC320/VDE 0625, i.e. plugging and removing under load
  • Corresponds to VDE 0628, i.e. use in installation systems
  • Compatible with the most common systems

AC 166 GBUPF/ 3 WHITE产地与重量

Country of origin Germany (DE)
Manufacturer Adels Contact
Gross weight (incl. package) 22.0 Gram
Dimensions (incl. package) 73 x 34 x 16 MM
Customs number 8536699099
UNSPSC (v5.03) 30211816
