7300 2744 -

Signal round plug Connectors EPIC? M23 Poles 8+1, 7300 2744, Lapp

Lapp 7300 2744
声明：图片仅供参考，请以实物为准！
制造商：
Lapp Lapp
制造商产品编号：
7300 2744
仓库库存编号：
144-03-137
技术数据表：
View 7300 2744 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

7300 2744技术参数

Series EPIC? M 23
Poles 8+1
Locking type Screw locking M23 x 1
Nominal current 7 A
Gender of contacts Male

7300 2744产品信息

Description Male inserts
Termination type Soldering Connection
Connection 0.14...1 mm2
Cable entry max. 13.5 mm
Rated voltage 150 VAC/DC
Housing Material Zinc (Zn)
Protection rating IP 68
Contact material Brass, gold-plated
Cable entry 7...13.5 mm
Temperature range -25...+125 °C

7300 2744配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
Related Products: Crimp contact female | Crimp contact male | Protective cap | Crimp contact Stamped, Female | Hex nut M8 x 0.5
Related Manufacturers: Binder | Amphenol | HARTING | Alpha Wire | Kabeltronik
Related Categories: Mains / Control Cables | Cable Glands | Cable Gland Locknuts | Cable Entry Systems | Equipment Wires
电话:400-900-3095
QQ:800152669

7300 2744Family Information

  • Secure protection against vibration, corrosion and EMC radiation
  • Simple and sure shield tie-up
  • With integrated labeling field and marking ring
  • Assembly without special tools

7300 2744产地与重量

Country of origin Germany (DE)
Manufacturer Lapp
Gross weight (incl. package) 9.0 Gram
Dimensions (incl. package) 28 x 18 x 18 MM
Customs number 8536699099
UNSPSC (v5.03) 30211814
EAN 4044773741506
