TPC-REM240-24 -

Redundancy module 24 - 27 VDC 10 A, TPC-REM240-24, Traco Power

Traco Power TPC-REM240-24
声明：图片仅供参考，请以实物为准！
制造商产品编号：
TPC-REM240-24
仓库库存编号：
110-50-201
技术数据表：
View TPC-REM240-24 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

TPC-REM240-24技术参数

Input voltage 24 VDC
Output voltage 24- 27 VDC
Output current 10 A
Dimensions W x H x D 45 x 90 x 96.5 mm
Width 45 mm
Height 90 mm
Depth 96.5 mm
Related Manufacturers: Mean Well | Würth Elektronik | Fischer Elektronik | Recom | TDK-Lambda
Related Categories: DC / DC Converters | AC / DC Converters | Power Supplies | Inductors | Heat Sinks
Related Products: Bracket for power supply | Front Panel SE..., MAX 3 HE 6 TE | Front Panel 3 TE | Power Saving Back-UPS Pro 550 330 W | Smart-UPS RT 19" rail kit 2HE (1000/2000 VA)
电话:400-900-3095
QQ:800152669

TPC-REM240-24Family Information

  • Allow to connect two outputs of TPC power supplies together
  • In normal operation the module achieves equal current share for both power supplies connected
  • During the redundancy operation, if one of the power supplies fails, the output power will be provided in full by the remaining operating power supply

TPC-REM240-24产地与重量

Country of origin Taiwan (TW)
Manufacturer Traco Power
Gross weight (incl. package) 228.0 Gram
Dimensions (incl. package) 140 x 130 x 45 MM
Customs number 8504403090
UNSPSC (v5.03) 30211502
