Instrument for |
Current
Loop Calibrator Resistance Voltage |
ADC max. | 1 ADC |
VDC max. | 1000 VDC |
Ohm max. | 40 MOhm |
Measuring function |
Current, apply/simulate
Continuity tester Diode tester Hold Min./max. value Relative mode |
Hz max. | 20 kHz |
VAC max. | 1000 VAC |
AAC max. | 1 AAC |
Type of measurement | TRMS AC |
Instrument functions | Backlight |
Description | Process multimeter |
ADC resolution | 1 μA |
VDC resolution | 100 μV |
Ohm resolution | 10 mOhm |
Hz resolution | 0.01 Hz |
VAC resolution | 100 μV |
AAC resolution | 1 μA |
Display |
LCD
Backlit |
Digits | 30000 |
Safety to EN61010 | CAT III 1000 V |
Electrical supply | 1 x 6LR61/9V |
Dimensions L x W x H | 201 x 98 x 52 mm |
Weight | 642 g |
Guarantee | 3 years |
Delivery with |
Battery
Crocodile clip Manual Protective holster yellow Test lead |
