STD-12160 -

Power supply 12 VDC/16.0 A, STD-12160, Nordic Power

Nordic Power STD-12160
声明：图片仅供参考，请以实物为准！
制造商产品编号：
STD-12160
仓库库存编号：
169-23-486
技术数据表：
View STD-12160 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

STD-12160技术参数

Output voltage 12 VDC
Output current max. 16.0 A
Efficiency 87 %
Input voltage 100...240 VAC
Power 192.0 W
Dimensions L x W x H 183.2 x 81 x 42.3 mm

STD-12160产品信息

Connection, primary side 3-pole C14 appliance inlet
Connection, secondary side DIN 4-p
Cable length 1.5 m
Input frequency 47...63 Hz
Input frequency max. 63 Hz
Input frequency min. 47 Hz
Width 81 mm
Height 42.3 mm
Short-circuit-proof Yes
电话:400-900-3095
QQ:800152669

STD-12160Family Information

  • Switching, fixed regulated output voltage
  • Protected against short circuits, over-voltage and over temperature
  • Wide input voltage range
  • Output provided with 1.5 m cable incl. 4-PIN DIN connector

STD-12160产地与重量

Country of origin China (CN)
Manufacturer Nordic Power
Gross weight (incl. package) 904.0 Gram
Dimensions (incl. package) 250 x 130 x 5 MM
Customs number 8504403090
UNSPSC (v5.03) 30211504
