169-63-410,Power inlet with filter 16 A 250 VAC, C20F.0001, Schurter
Datasheet
| Rated voltage | 250 VAC |
| Rated current | 16 A |
| Rated inductance | 20.3 nH(2x) |
| X" type="checkbox" name="Capacitance, CX" /> X">Capacitance, CX | 100 nF |
| Y" type="checkbox" name="Capacitance, CY" /> Y">Capacitance, CY | 2.2 nF |
| Termination type | Soldering Contacts |
| IEC-climate category | 25/085/21 |
| Leakage current | <0.5 mA |
| Resistance | 1 MOhm |
| Description | Standard filter for screw fastening |
| Temperature range | -25...+85 °C |
