5120.0306.0 -

Power inlet with filter 10 A 250 VAC, 5120.0306.0, Schurter

Schurter 5120.0306.0
声明:图片仅供参考,请以实物为准!
制造商产品编号:
5120.0306.0
仓库库存编号:
169-63-160
技术数据表:
View 5120.0306.0 Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

5120.0306.0技术参数

Rated voltage 250 VAC
Rated current 10 A
Rated inductance 0.4 mH(2x)
X" type="checkbox" name="Capacitance, CX" /> X">Capacitance, CX 100 nF

5120.0306.0产品信息

Termination type Faston 6.3 x 0.8 mm
IEC-climate category 25/085/21
Leakage current <5 μA
Resistance 1 MOhm
Description Medical version, protection class I
Temperature range -25...+85 °C

5120.0306.0配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
Related Products: Ferrite SMD 0.5 A 0.3 Ohm 1206 | Ferrite SMD 4.6 x 3.1 x 3 mm 50 Ohm | Ferrite SMD 0.15 A 1.5 Ohm 0504 | Ferrite SMD 4 A | Ferrite SMD 1 A 0.2 Ohm 1206
Related Categories: Fuses | Filters | Mains Connectors & Device Plugs | Fuse Holders | SMD Fuses
Related Manufacturers: Würth Elektronik | Littelfuse | Apem | S.A Bourqui Jean | RAFI
电话:400-900-3095
QQ:800152669

5120.0306.0Family Information

  • Compact, high-quality filter
  • Device connector protection class I and network filter in standard and medicinal version
  • Standard version: Screw fastening from back side with M3 screws (thread in metal flange)
  • Medicinal version: Screw fastening from front or rear side with M3 screws and nuts or rivets
  • Conforms to IEC/EN 60950

5120.0306.0产地与重量

Country of origin Switzerland (CH)
Manufacturer Schurter
Gross weight (incl. package) 40.18 Gram
Dimensions (incl. package) 55 x 47 x 34 MM
Customs number 8536301090
UNSPSC (v5.03) 30211501
