300-77-150,PCB Terminal Block Series 713 Pitch 3.5 mm horizontal 6P, 713-1423, Wago
| Connection direction | horizontal |
| Rated voltage to EN | 250 V |
| Rated current to EN | 10 A |
| Connection cross-section | 0.8 x 0.8 mm angled pins |
| Termination type | Solder-In Pins, 90° Angled |
| Rated current to UL | 10 A |
| Colour | black |
| Series | 713 |
| Pitch | 3.5 mm |
| Poles | 6 |
| Rated voltage to UL | 80 V |
| Test voltage | 2.5 kV |
| Housing Material | Polyphthalamide (PPA) |
| Temperature range | -60...+100 °C |
| Max. temperature | +100 °C |
| Min. Temperature | -60 °C |
