148-33-610,PCB Terminal Block Pitch 3.5 mm horizontal 2P, AK1350/02-3.5, PTR Messtechnik
Datasheet
| Connection direction | horizontal |
| Rated voltage to EN | 160 VAC/DC |
| Rated current to EN | 8 A |
| Connection cross-section | 0.08...1.5 mm2 solid or stranded |
| Termination type | Screw Connection |
| Rated current to UL | 9 A |
| Pitch | 3.5 mm |
| Poles | 2 |
| Rated voltage to UL | 150 VAC/DC |
| Test voltage | 2.5 kV |
| Housing Material | Polyamide (PA 66) |
| Temperature range | -30...+105 °C |
| Max. temperature | +105 °C |
| Min. Temperature | -30 °C |
| 型号 | 制造商 | 描述 | 操作 |
| AK1350/02-3.5 [更多] | PTR Messtechnik GmbH & Co KG | Pluggable Terminal Block Rating to EN: 8 A @ 160 VAC/VDC Rating to UL: 9 A @ 150 VAC/VDC Temperature range: -30 ... 105 °C Connection cross-section: 0.08...1.5 mm2 solid or stranded Connection direction: Horizontal Housing Material: Polyamide (PA 66) Pitch: 3.5 mm Termination type: Screw Connection Poles: 2 Rated current to EN: 8 A Rated current to UL: 9 A Rated voltage to EN: 160 VAC/VDC Rated voltage to UL: 150 VAC/VDC | 搜索 查看资料 |
