PK 7002 -

PCB Terminal Block Pitch 5 mm horizontal 2P, PK 7002, Hartmann/PTR

Hartmann/PTR PK 7002
声明:图片仅供参考,请以实物为准!
制造商产品编号:
PK 7002
仓库库存编号:
148-40-952
技术数据表:

订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

PK 7002技术参数

Connection direction horizontal
Rated voltage to EN 250 VAC/DC
Rated current to EN 24 A
Connection cross-section 4 mm2 solid 2.5 mm2 stranded
Termination type Screw Connection

PK 7002产品信息

Rated current to UL 20 A
Pitch 5 mm
Poles 2
Rated voltage to UL 300 VAC/DC
Test voltage 2 kV
Housing Material Polyamide (PA 66)
Temperature range -30...+105 °C
Combustibility class UL 94 V-0
Max. temperature +105 °C
Min. Temperature -30 °C
Related Manufacturers: Phoenix Contact | Weidmüller | Wago | RND Connect | Würth Elektronik
Related Categories: Terminal Blocks
Related Products: Pin header, straight Solder Pin [PCB, Through-Hole] 4P | Pin header, straight Solder Pin [PCB, Through-Hole] 3P | Pin header, straight Solder Pin [PCB, Through-Hole] 5P | Pin header, straight Solder Pin [PCB, Through-Hole] 2P | PCB Terminal Block Pitch 5 mm horizontal 2P
电话:400-900-3095
QQ:800152669

PK 7002Family Information

  • With elevator terminal principle

PK 7002产地与重量

Country of origin Germany (DE)
Manufacturer Hartmann/PTR
Gross weight (incl. package) 4.0 Gram
Dimensions (incl. package) 25 x 10 x 10 MM
Customs number 8536693000
UNSPSC (v5.03) 30211801
