300-08-272,PC Oscilloscope 4x70 MHz 0.25 GS/s, PS3404DMSO, Pico
| Channel analog | 4 |
| Channel digital (MSO) | 16 |
| Bandwidth | 70 MHz |
| Sample rate, single-shot | 0.25 GS/s |
| Memory | 32000 kpts/ch |
| Trigger |
Auto
Edge Logic Normal Pulse width Rise/Fall Time Runt Sequence (B-trigger) Single Video |
| Sample rate, repetitive | 2.5 GS/s |
| Measuring function |
Automatic parameter measurement
Cursor measuring Duty cycle Internal memory Mask testing Min./max. value |
| Instrument functions |
Arbitrary wavefrom generator
Bus decoding Function Generator Spectrum Analyser |
| Rise Time | 5.8 ns |
| Vertical sensitivity/div | 4 mV...4 V/div |
| Time basis | 1 ns...5000 s/div |
| Vertical resolution | 8 Bit |
| Input impedance Ohm | 1 MOhm |
| Input: Impedance F | 14 pF |
| Input coupling |
AC
DC |
| Mathematical functions |
Add
Subtract Multiply Divide Integrate Differentiate FFT Advanced Math |
| Interfaces | USB |
| Dimensions L x W x H | 170 x 190 x 40 mm |
| Weight | 0.5 kg |
| Electrical supply |
USB
Plug-in power supply |
| Guarantee | 5 years |
| Delivery with |
1 Probes/channel
Digital cable Documentation CD Printed Quick Start Guide Power cable Power supply Test clip Software USB cable |
