144-76-113,Panel-mount plug, 713 series 4-pole M12, 09-3433-00-04, Binder
Datasheet
| Poles | 4 |
| Gender of contacts | Male |
| Series | 713 |
| Connector Design |
Square Flange
straight |
| Protection rating | IP 40 |
| Locking type | Screw locking M12 x 1 |
| Size | M12 |
| Rated current | 4 A |
| Termination type | Stranded Wires, Prepared |
| Contact material | CuSn(Zn)+Au |
| Cable length | 0.2 m |
| Rated voltage | 250 VAC/DC |
| Housing Material | Metal |
| Fastening | Square flange |
| Connection max. | 0.25 mm2 |
| Max. temperature | +85 °C |
| Connection | 0.25 mm2 |
| Temperature range | -25...+85 °C |
| Description | Panel-mount plugs with square flange and 0.2 m strands 0.25 mm2 |
