176-25-148,Oscilloscope 2x500 MHz 5 GS/s, TDS3052C, Tektronix
Datasheet
| Series | TDS3000 |
| Channel analog | 2 |
| Channel digital (MSO) | 0 |
| Bandwidth | 500 MHz |
| Sample rate, single-shot | 5 GS/s |
| Memory | 10 kpts/ch |
| Display | 6.5" TFT-LCD |
| Trigger |
Auto
Edge Normal Pulse width Rise/Fall Time Runt Logic Single Video |
| Safety standard EN 61010 | CAT II 300 V |
| Interfaces |
USB Device (Control and Connect with a PC)
USB host (Data Storage To USB Stick) Ethernet (LAN) |
| Type of measurement | RMS |
| Measuring function |
Automatic parameter measurement
Cursor measuring Mask testing (optional) Min./max. value RPM measurement |
| Instrument functions |
Analogue bargraph
Battery Operation (optional) Zoom function Probe-Interface |
| Rise time | 0.7 ns |
| Vertical sensitivity/div | 1 mV...10 V/div |
| Time basis | 1 ns...10 s/div |
| Vertical resolution | 9 Bit |
| Electrical supply |
100...240 V @ 50...60 Hz
Li-ion battery |
| Mathematical functions |
Add
Subtract Multiply Divide FFT Advanced Math |
| Input coupling |
AC
DC GND |
| Input impedance Ohm |
1
MOhm
50 MOhm |
| Input: Impedance F | 13 pF |
| Dimensions L x W x H | 149 x 375 x 176 mm |
| Weight | 3.2 kg |
| Guarantee | 3 years |
| Delivery with |
1 Probes/channel
Documentation CD Manual Power cable Software Calibration certificate Translated front-panel overlay |
| 型号 | 制造商 | 描述 | 操作 |
| TDS3052C [更多] | Tektronix Inc | Oscilloscope Dimensions L x W x H: 149 x 375 x 176 mm Time basis: 1 ns...10 s/div Vertical sensitivity/div: 1 mV...10 V/div Weight: 3.2 kg Delivery with: 1 Probes / Channel / Documentation CD / Manual / Power Cable / Software / Calibration Certificate / Translated Front-panel Overlay Design: Bench Display: 6.5" TFT-LCD Electrical supply: 100...240 V @ 50...60 Hz / Li-ion battery Guarantee: 3 Years Input coupling: AC / DC / GND Input impedance Ohm: 1 MOhm / 50 Ohm Instrument functions: Analogue Bargraph / Battery Operation (Optional) / Zoom Function / Probe-Interface Interfaces: USB Device (Control and Connect with a PC) / USB host (Data Storage To USB Stick) / Ethernet (LAN) Mathematical functions: Add / Subtract / Multiply / Divide / FFT / Advanced Math Measuring function: Automatic parameter measurement / Cursor measuring / Mask testing (optional) / Min./max. value / RPM measurement Safety s
| 搜索 查看资料 |
| 参考图片 | 制造商 / 说明 / 型号 / 仓库库存编号 | 操作 | |
| Tektronix Oscilloscope 2x500 MHz 5 GS/s, TDS3052C, Tektronix 型号：TDS3052C 仓库库存编号：176-25-148 | | 搜索 |
| 参考图片 | 型号/品牌 | 描述 / 技术参考 | 操作 |
 | TDS3052C Tektronix | 示波器，数字式磷光，500MHz，2 输入 通道，Tektronix，TDS3052C | 查价格库存 查看详细 |
 | TDS3052C CAL TEKTRONIX | 原厂原装货 暂无PDF | 查价格库存 查看详细 |
| 制造商产品编号 | 仓库库存编号 | 制造商 / 说明 / 规格书 | 操作 |
TDS3052C | 1554159 | TEKTRONIX 2 Channel Digital Phosphor Oscilloscope offering up to 500MHz Bandwidth and USB Connectivity (EN) | 搜索 |
| 参考图片 | 制造商 / 说明 / 型号 / 仓库库存编号 | 操作 | |
 | Tektronix Digital Oscilloscope, 2 Ch, 500MHz TDS3052C 型号：TDS3052C 仓库库存编号：70136874 |  | 搜索 |
| 产品描述 / 参考图片 | 制造商零件编号 / 制造商 / 库存编号 | 操作 | ||
| 制造商零件编号： TDS3052C 品牌： Tektronix 库存编号： 462-994 | 搜索 |
Adapted for measurements by designers, production and test engineers within communications, computer/peripheral equipment and video systems.
