RADOX 125 4G1,5 MM2 -

Mains cable 4 x1.50 mm2 Stranded tin-plated copper wire unshielded RADOX? 125 black, RADOX 125 4G1,5 MM2, Huber+Suhner

Huber+Suhner RADOX 125 4G1,5 MM2
声明：图片仅供参考，请以实物为准！
制造商产品编号：
RADOX 125 4G1,5 MM2
仓库库存编号：
155-60-669
技术数据表：
View RADOX 125 4G1,5 MM2 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

RADOX 125 4G1,5 MM2技术参数

Cable type Mains cable
Cross-section 1.50 mm2
Cross-section AWG 15 AWG
Cores 4
Packaging Sold by meter
Conductor Stranded tin-plated copper wire
Sheath colour black
Shielding unshielded
Conductor insulation RADOX? 125

RADOX 125 4G1,5 MM2产品信息

Halogen-free Yes
Core colours brown
yellow/green
black
grey
Sheath RADOX 125
Design Halogen-Free
Flame-Retardant
Oil-Proof
Shielding material -
Test voltage 3500 VAC
Min. Temperature -40 °C
Max. temperature +125 °C
Max. temperature range, transient +190 °C
Rated voltage 600 VAC/DC
? Sheath 9.2 mm
Temperature range -40...+125 °C

RADOX 125 4G1,5 MM2替代产品

RADOX 125 4G1,5 MM2配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
Related Categories: Equipment Wires | RF / Coaxial Connectors | Cable Assemblies | Mains / Control Cables | Data & RF Cables
Related Manufacturers: Molex | TE Connectivity | Würth Elektronik | Alpha Wire | Kabeltronik
Related Products: Control cable 5 x 0.25 mm2 unshielded Bare copper stranded wire black | Control cable 2 x 0.25 mm2 unshielded Bare copper stranded wire black | Control cable 5 x 0.25 mm2 shielded Bare copper stranded wire black | Control cable 2 x 0.14 mm2 unshielded Bare copper stranded wire grey | Mains cable 2 Cores, 2 x0.75 mm2 Bare copper stranded wire unshielded PVC black
电话:400-900-3095
QQ:800152669

RADOX 125 4G1,5 MM2Family Information

Series Description
  • Suitable for controls and system design
  • Halogen-free and flame resistant
  • High resistance to chemicals and environmental influences
  • Suitable for exterior applications

RADOX 125 4G1,5 MM2产地与重量

Country of origin Switzerland (CH)
Manufacturer Huber+Suhner
Gross weight (incl. package) 133.0 Gram
Dimensions (incl. package) 1.000 x 9 x 9 MM
Customs number 8544499500
UNSPSC (v5.03) 26121603
