Ohm max. | 200 MOhm |
F max. | 20 mF |
H max. | 20000 H |
Ohm resolution | 1 mOhm |
F resolution | 0.01 pF |
H resolution | 0.001 μH |
Dissipation factor D min. | 0.001 |
Dissipation factor D max. | 1999 |
Quality factor Q min. | 0.001 |
Quality factor Q max. | 1999 |
Measurement frequency |
fix 100 Hz
fix 120 Hz fix 1 kHz fix 10 kHz fix 100 kHz |
Measuring function |
L
C R Q D DCR ESR |
Interfaces | USB |
Display | LCD |
Electrical supply |
6 x LR03/AAA
12 VDC |
Weight | 495 g |
Dimensions L x W x H | 210 x 100 x 45 mm |
Delivery with |
USB cable
Battery Carrying case Kelvin probe Manual Software |
