169-85-154,Laboratory Power Supply 2 Ch. 0...75 VDC 2 A / 0...75 VDC 2 A, EX752M, Aim-TTi
Datasheet
| Outputs | 2 |
| Power | 300 W |
| Output voltage 1 max. | 75 VDC |
| Output current 1 max. | 2 A |
| Output voltage 2 max. | 75 VDC |
| Output current 2 max. | 2 A |
| Resolution, voltage | 100 mV |
| Description | Laboratory power supply, dual voltage |
| Length | 320 mm |
| Input voltage | 230 VAC |
| Dimensions L x W x H | 320 x 260 x 160 mm |
| Weight | 4.4 kg |
Dual voltage power supply with 2 totally separate and isolated outputs. The output voltage of each output is adjustable with 0-75 V with adjustable current limit 0-2 A. The outputs can easily be connected in series or parallel via a front panel switch, which will enable the unit to supply 0-75 V with a current range of 0-4 A or 0-150 V with 0-2 A. By combining switch-mode and linear technology, advantages like low power loss (no fan cooling) and low weight are gained. At the same time, an output voltage with low noise and ripple is obtained. A logarithmic curve for current adjustment makes it possible to set low current values very precisely. Digital voltage and current meters that use 14 mm high LED displays. Each output has a power switch.
