125-20-326,KVM switch AutoView 1515 2->8-port VGA PS/2 / USB, AV1515-202, Avocent
Datasheet
| Number of PCs / servers | 8 |
| Number of consoles | 2 |
| Mouse / keyboard connection |
PS/2
USB |
| Monitor connection | VGA |
| Construction form | 19" Rackmount |
| Switching |
OSD
HotKey Autoscan |
| LAN / IP access | No |
| Resolution max. local | 1600 x 1200 |
| USB-Hub | No |
| Audio-support | No |
| Cascading | Yes |
| Connection, console | 2 x VGA, 4 x PS/2 |
| Connection, PC | 8 x RJ45, via cable adapter |
| Resolution max. IP | - |
| Audio connections | - |
| Power supply | Built-in power supply unit |
| Special feature | Space-saving cat. 5 cabling concept |
| Dimensions W x H x D | 432 x 44 x 279 mm |
| Weight | 3.6 kg |
| On-Screen-Display (OSD) | Yes |
Up to two users have direct local rack access to up to 16 PS/2, Sun or USB servers. The Cat. 5 cable adapters offers a simple, space-saving, see-at-a-glance connection between servers and switches. A built-in memory assigns the computers dedicated ID codes. In this way, servers are easily identified and addressed from their code and not via a port, thereby greatly simplifying reconfiguring.
