HD300 -

IR Thermo-Anemometer 0.4...30 m/s 0...16665 m3/h -10...+60 °C, HD300, Extech Instruments

Extech Instruments HD300
声明:图片仅供参考,请以实物为准!
制造商产品编号:
HD300
仓库库存编号:
110-71-588
技术数据表:
View HD300 Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

HD300技术参数

No. of inputs 3
Instrument for Air flow
Temperature
Wind speed
Wind speed min. 0.4 m/s
Wind speed max. 30 m/s

HD300产品信息

Min. Temperature -10 °C
Max. temperature +60 °C
Temperature range, IR -50...+500 °C
Air flow rate min. 0 m3/h
Air flow rate max. 16665 m3/h
Sensor type/thermocouples Infrared/NTC
Interfaces USB
Resolution, wind speed 0.01 m/s
Resolution, temperature max. 0.1 °C
Resolution, temperature IR 0.1 °C
Resolution, air flow 0.001 m3/h
Measuring error, wind speed ±3%
Measuring error °C ±2 °C
Electrical supply 1 x 6LR61/9V
Dimensions L x W x H 203 x 75 x 50 mm
Delivery with Battery
Hard case
Software
USB cable

HD300配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
电话:400-900-3095
QQ:800152669

HD300Family Information

  • Thermo-Anemometer with built-in non-contact IR Thermometer and Laser Pointer
  • Displays air velocity, air flow, temperature of air, and surface temperature using IR thermometer
  • InfraRed Thermometer measures remote surface temperatures to 500 °C with 30:1 distance to spot ratio
  • Air Temperature -10...60 °C (built into the vane assembly)
  • 20 point average for air flow
  • Data Hold and Max/Min/Avg
  • Software allows the user to view and save readings to the PC

HD300产地与重量

Country of origin China (CN)
Manufacturer Extech Instruments
Gross weight (incl. package) 871.0 Gram
Dimensions (incl. package) 1 x 1 x 1 MM
Customs number 9025804089
UNSPSC (v5.03) 41113630
EAN 793950103005
