176-80-424,Intrinsically safe current loop calibrator, FLUKE 707EX, Fluke
Datasheet
| Instrument for |
Current
Loop Calibrator Voltage |
| ADC max. | 24 mA |
| VDC max. | 28 VDC |
| Measuring function | Current, apply/simulate |
| Description | Intrinsically safe current loop calibrator |
| ADC resolution | 1 μA |
| VDC resolution | 1 mV |
| Display | LCD |
| Electrical supply | 1 x 6LR61/9V |
| Dimensions L x W x H | 164 x 75 x 47 mm |
| Weight | 350 g |
Handheld instrument for calibration, maintenance and repairs with high accuracy. Large wheel for easy one-hand manoeuvring and setting of parameters. Measures and powers a 4–20 mA current loop. Displays mA and % at the same time. Choice of fast or slow ramping/step-by-step operation provides even out-signals at changes and loop-function tests. Span Check for fast confirmation of set range. Integral voltage source of 24 V. 3 year warranty.
