Voltage | 2...550 VAC/DC |
Insulation | 10 kOhm...2 GOhm |
Test voltage | 50, 100, 250, 500, 1000 VDC |
FI circuit breaker | 10, 30, 100, 300, 500, 650, 1000 mA |
Plug version | F (CEE 7/4) |
Continuity | 0.01 Ohm...399.9 kOhm |
Earthing | 0.1 Ohm...4 kOhm |
Measuring function |
Automatic insulation measurement
Fault current/current Phase sequence Storage of release time and tripping current |
Frequency | 15.3...500 Hz |
Loop (Zs and Zi) | 0.1...4000 Ohm (without release of FI-circuit breaker ≥ 30 mA) |
Safety | CAT III 600 V |
Protection rating | IP 53 |
Electrical supply | Rechargeable battery |
Dimensions L x W x H | 280 x 190 x 128 mm |
Weight | 2.4 kg |
