540-88-028-24-000-1 -

IC sockets, PLCC 28, 540-88-028-24-000-1

540-88-028-24-000-1
声明：图片仅供参考，请以实物为准！
制造商：
制造商产品编号：
540-88-028-24-000-1
仓库库存编号：
148-14-873
技术数据表：
View 540-88-028-24-000-1 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

540-88-028-24-000-1技术参数

Poles 28
Pitch 2.54 mm
Insulation resistance ≥ 5000 MOhm
Insertion resistance ≤20 mOhm
Rated voltage 150 VDC

540-88-028-24-000-1产品信息

Operating temperature -55...+125 °C
Insulator material glass-fibre-reinforced thermoplastic, PPS, as per UL 94 V-0
Rated current 2 A
A 17.52 mm
B 17.52 mm
C 7.62 mm
Capacitance ≤2 pF
Contact body material Phosphor bronze
Surface of contact sleeve Tin-plated
Electric strength >600 VRMS
电话:400-900-3095
QQ:800152669

540-88-028-24-000-1Family Information

  • Designed for JEDEC MO 047/052
  • With supporting cams and ventilation sections
  • Optical polarisation aids
  • With sections for extracting tool
  • Suitable for infrared- and reflow-soldering

540-88-028-24-000-1产地与重量

Country of origin Switzerland (CH)
Gross weight (incl. package) 3.0 Gram
Dimensions (incl. package) 18 x 18 x 10 MM
Customs number 8536693000
UNSPSC (v5.03) 30211816
