176-23-804,Handheld Oscilloscope ScopeMeter 2x40 MHz 0.025 GS/s, FLUKE 125/001, Fluke
Datasheet
| Series | ScopeMeter |
| Channel analog | 2 |
| Bandwidth | 40 MHz |
| VDC max. | 1250 VDC |
| Sample rate, single-shot | 0.025 GS/s |
| Display | Mono |
| Memory | 1 kpts/ch |
| VDC resolution | 100 μV |
| Sample rate, repetitive | 1.25 GS/s |
| Safety standard EN 61010 | CAT III 600 V |
| Protection rating | IP 51 |
| VAC max. | 1250 VAC |
| Ohm max. | 30 MOhm |
| F max. | 500 μF |
| Hz max. | 70 MHz |
| Measuring function |
Continuity tester
Cursor measuring Data logger Diode tester Duty cycle Internal memory Min./max. value RPM measurement |
| Time basis | 10 ns...60 s/div |
| Vertical resolution | 8 Bit |
| Interfaces | RS232 |
| Rise Time | 8.75 ns |
| Input coupling |
AC
DC |
| Input impedance Ohm | 1 MOhm |
| Input: Impedance F | 12 pF |
| Vertical sensitivity/div | 5 mV...500 V/div |
| Electrical supply |
Battery pack
Mains power battery charger |
| VAC resolution | 100 μV |
| Ohm resolution | 0.1 Ohm |
| Hz resolution | 0.01 Hz |
| F resolution | 1 nF |
| Dimensions L x W x H | 232 x 115 x 50 mm |
| Weight | 1.2 kg |
| Delivery with |
1 Probes/channel
Rechargeable battery BNC Adapter Mains power battery charger Sprung Hook Crocodile clip Test lead Current Clamp |
