110-39-053,Handheld Oscilloscope Keysight U1600 2x40 MHz 200 MS/s, U1604B+001, Keysight
Datasheet
| Series | Keysight U1600 |
| Channel analog | 2 |
| Bandwidth | 40 MHz |
| VDC max. | 600 VDC |
| Sample rate, single-shot | 200 MS/s |
| Display |
4.5" TFT-LCD
Colour |
| Trigger |
Auto
Edge Normal Pattern Pulse width Single Video |
| Memory | 125 kByte |
| VDC resolution | 100 μV |
| Sample rate, repetitive | 2.5 GS/s |
| Safety standard EN 61010 |
CAT III 300 V
CAT II 600 V |
| VAC max. | 600 VAC |
| Ohm max. | 60 MOhm |
| F max. | 300 μF |
| Measuring function |
Continuity tester
Cursor measuring Data logger Diode tester |
| Instrument functions | Insulated independent inputs |
| Time basis | 10 ns...50 s/div |
| Vertical resolution | 8 Bit |
| Interfaces |
USB host (Data Storage To USB Stick)
USB |
| Rise Time | 8.8 ns |
| Type of measurement | TRMS |
| Input coupling |
AC
DC GND |
| Input impedance Ohm | 1 MOhm |
| Input: Impedance F | 20 pF |
| Vertical sensitivity/div | 5 mV...100 V/div |
| Mathematical functions |
Add
FFT Subtract |
| Electrical supply |
Battery pack
Mains power battery charger |
| VAC resolution | 100 μV |
| Ohm resolution | 0.1 Ohm |
| F resolution | 0.01 nF |
| Dimensions L x W x H | 241 x 138 x 66 mm |
| Weight | 1.5 kg |
| Delivery with |
1 Probes/channel
Crocodile clip Mains power battery charger Rechargeable battery Test lead Calibration certificate USB cable |
