176-22-909,Handheld Oscilloscope Keysight U1600 2x200 MHz 2 GS/s, U1620A, Keysight
Datasheet
| Series | Keysight U1600 |
| Channel analog | 2 |
| Bandwidth | 200 MHz |
| VDC max. | 1000 VDC |
| Sample rate, single-shot | 2 GS/s |
| Display |
5.7" TFT-LCD
Colour |
| Trigger |
Auto
CAN Edge LIN Normal Single TV |
| Memory | 2 Mpts/ch |
| VDC resolution | 100 μV |
| Safety standard EN 61010 |
CAT III 300 V
CAT III 600 V CAT II 1000 V |
| VAC max. | 1000 VAC |
| Ohm max. | 100 MOhm |
| F max. | 10 mF |
| Hz max. | 1 MHz |
| Measuring function |
Continuity tester
Cursor measuring Data logger Diode tester Duty cycle |
| Instrument functions | Insulated independent inputs |
| Time basis | 2 ns...50 s/div |
| Vertical resolution | 8 Bit |
| Interfaces | USB |
| Rise Time | 1.75 ns |
| Type of measurement | TRMS |
| Input coupling |
AC
DC |
| Input impedance Ohm | 1 MOhm |
| Input: Impedance F | 22 pF |
| Vertical sensitivity/div | 2 mV...50 V/div |
| Mathematical functions |
Add
Divide FFT Integrate Multiply Subtract |
| Electrical supply |
Li-ion battery
Mains power battery charger |
| VAC resolution | 100 μV |
| Ohm resolution | 0.1 Ohm |
| Hz resolution | 0.01 Hz |
| F resolution | 0.1 nF |
| Dimensions L x W x H | 183 x 65 x 270 mm |
| Weight | 2.5 kg |
| Delivery with |
1 Probes/channel
Mains power battery charger Rechargeable battery Test lead Calibration certificate USB cable |
