FK-MC 0,5/ 5-ST-2,5 -

Female header Spring Clamp Terminals 5P, FK-MC 0,5/ 5-ST-2,5, Phoenix Contact

Phoenix Contact FK-MC 0,5/ 5-ST-2,5
声明：图片仅供参考，请以实物为准！
制造商产品编号：
FK-MC 0,5/ 5-ST-2,5
仓库库存编号：
148-45-608
技术数据表：
View FK-MC 0,5/ 5-ST-2,5 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

FK-MC 0,5/ 5-ST-2,5技术参数

Pitch 2.5 mm
Poles 5
Gender of contacts Female

FK-MC 0,5/ 5-ST-2,5产品信息

Connection direction straight
Termination type Spring Clamp Terminals
Rated voltage to EN 125 VAC/DC
Rated current to EN 4 A
Cross-section max. 0.5 mm2
Cross-section min. 0.14 mm2
Manufacturer Article n° 1881354
Rated voltage to UL 125 VAC/DC
Rated current to UL 4 A
Connection cross-section 0.14 ... 0.5 mm2 solid or stranded
Housing Material Polyamide (PA/Nylon)

FK-MC 0,5/ 5-ST-2,5关联产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作

FK-MC 0,5/ 5-ST-2,5您可能还对以下元器件感兴趣

Related Categories: Terminal Blocks | RCD & Over-voltage Protection | Sensor Cables, Distributors & Testers | Transmitter & Converters | AC / DC Converters
Related Products: Pin header, straight Solder Pin [PCB, Through-Hole] 4P | Pin header, straight Solder Pin [PCB, Through-Hole] 3P | Pin header, straight Solder Pin [PCB, Through-Hole] 5P | Pin header, straight Solder Pin [PCB, Through-Hole] 2P | PCB Terminal Block Pitch 5 mm horizontal 2P
Related Manufacturers: Weidmüller | Binder | Mean Well | Hammond | Amphenol
电话:400-900-3095
QQ:800152669

FK-MC 0,5/ 5-ST-2,5Family Information

  • Terminal block in two parts that can be separated, one part for cable connection and one part for PCB mounting
  • The plug is connected using spring-loaded connection

FK-MC 0,5/ 5-ST-2,5产地与重量

Country of origin Germany (DE)
Manufacturer Phoenix Contact
Gross weight (incl. package) 3.0 Gram
Dimensions (incl. package) 18 x 13 x 13 MM
Customs number 8536693000
UNSPSC (v5.03) 30211801
EAN 4017918156602
