144-35-426,Female connector Pitch5.08 mm Poles 15 SMS-Qikmate, SMS15SE3K9, Souriau
Datasheet
| Pitch | 5.08 mm |
| Poles | 15 |
| Series | SMS-Qikmate |
| Gender of contacts | Female |
| Gender of housing | Male |
| Housing Material | Polyamide (PA 66) |
| Connection principle | Wire-Board |
| Contact material | CuNi+Au |
| Rated current | 13 A |
| Rated voltage | 500 VAC |
| Test voltage | 2 kV |
| A | 16.2 mm |
| B | 34.3 mm |
| C | 10.2 mm |
| D | 13.4 mm |
| E | 26.1 mm |
| Insulation resistance | 5000 MOhm |
| Temperature range | -55...+105 °C |
| Combustibility class | UL 94 V-2 |
