UT 35 -

Feed-through terminal block N/A grey, 1.5...50 mm2, 3044225, UT 35, Phoenix Contact

Phoenix Contact UT 35
声明:图片仅供参考,请以实物为准!
制造商产品编号:
UT 35
仓库库存编号:
300-12-611
技术数据表:
View UT 35 Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

UT 35技术参数

Rated current 125 A
Rated voltage 1000 VAC
Housing Material Polyamide (PA/Nylon)
Colour grey

UT 35产品信息

Cross-section, rigid 1.5...50 mm2
Cross-section, flexible 1.5...50 mm2
Connection Screw
Combustibility class UL 94 V-0
Width 16 mm
Mounting DIN Rail
Poles 2
Manufacturer Article n° 3044225

UT 35配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
电话:400-900-3095
QQ:800152669

UT 35Family Information

  • Connection method: Screw connection
  • The reducing bridges can be used to connect terminal blocks with different connection technologies, e.g., UT 35 screw terminal block with Push-in Technology 2,5 Push-in terminal blocks, to form power blocks
  • Tested for railway applications
  • Easy and time-saving potential supply and distribution of large currents and cross sections up to 35 mm2 with reducing bridges

UT 35产地与重量

Country of origin Turkey (TR)
Manufacturer Phoenix Contact
Gross weight (incl. package) 61.0 Gram
Dimensions (incl. package) 65 x 60 x 18 MM
Customs number 8536901000
UNSPSC (v5.03) 30211801
EAN 4017918977559
