Cable type | Drag chain cable |
Cross-section | 1.50 mm2 |
Cross-section AWG | 15 AWG |
Cores | 3 |
Packaging | Sold by meter |
Conductor | Bare copper stranded wire |
Sheath colour | silver-grey (RAL 7001) |
Shielding | unshielded |
Min. bending radius, moving | 5 x conductor ? |
Min. bending radius, not moving | 3 x conductor ? |
Temperature range, moving | -40...+80 °C |
Core insulation | TPE |
Rated voltage | 300/500 VAC/DC |
Temperature range, not moving | -50...+80 °C |
Test voltage | 3000 V |
Sheath | PUR |
Stranding | Cores stranded in layers |
Taping | Special protective winding over every stranding layer |
Core colours | black numbered |
? Sheath | 7.6 mm |
Manufacturer Article n° | 0027576 |
