169-53-465,DC/DC converter 12 VDC 100 W, TZL 100-2412, Traco Power
Datasheet
| Input voltage | 18...36 VDC |
| Output voltage 1 | 12 VDC |
| Output current 1 | 8.5 A |
| Power | 100 W |
| Galvanic isolation | Yes |
| Operating temperature | -10...+70 °C |
| Dimensions L x W x H | 208 x 95 x 38 mm |
| Efficiency | 80 %typ. |
| System deviation, supply | ±1.0% |
| System deviation, load | ±1.0% |
| No-load current (stand-by) | 200 mA |
| Residual ripple | <150 mVpp |
| Derating | from 50 °C |
| Insulation voltage | 1500 VDC |
| Short-circuit strength | continuous |
| Weight | 700 g |
| Connection, primary side | Screw terminals |
| Connection, secondary side | Screw terminals |
