Type of measurement | TRMS AC |
W max. | 750 kW |
AAC max. | 1000 AAC |
Accuracy, current, AC | ±2.0 %+ 5 digits |
VAC max. | 750 VAC |
Max. conductor ? | 55 mm |
Reactive power | 750 kVar |
Apparent power | 750 kVA |
Total power factor | 0.3...1 |
Hz max. | 200 Hz |
Safety to EN61010 | CAT III 1000 V |
W resolution | 10 W |
AAC resolution | 100 mA |
VAC resolution | 0.1 V |
Hz resolution | 1 Hz |
Bandwidth AAC | 0.06 kHz |
Display | LCD, 9999 measurement points, with analogue bar display |
Interfaces | USB |
Energy measurement | 1...9999 kWh |
Instrument functions |
Analogue bargraph
Memory Non-contact voltage detection |
Measuring function |
Hold
Min./max. value |
Dimensions L x W x H | 295 x 100 x 45 mm |
Weight | 540 g |
Electrical supply | 1 x 6LR61/9V |
Delivery with |
Battery
Carrying case Manual Software Test lead USB cable |
