STAS 200 -

Cable connector, 2p+E, STAS 200, Belden Hirschmann

Belden Hirschmann STAS 200
声明:图片仅供参考,请以实物为准!
制造商产品编号:
STAS 200
仓库库存编号:
143-86-532
技术数据表:
View STAS 200 Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

STAS 200技术参数

Rated current 10 ADC
16 AAC
Poles 2+PE
Gender of contacts Male
Termination type Screw Connection

STAS 200产品信息

Protection rating IP 54
Cable entry max. 6.5 mm
Connection max. 1.5 mm2
Colour grey
Rated voltage 250 VAC
250 VAC
Contact material CuZn+Sn
Sealing cap PG 7
Locking type Circlip
Housing Material Polyamide (PA/Nylon)
Max. temperature +90 °C
Cable entry 4...6.5 mm
Description with strain-relief
with coding driver
Temperature range -30...+90 °C
Related Categories: Rectangular Connectors | Circular Connectors | Audio / Video / Computer Connectors | Industrial Ethernet | Industrial Communication
Related Products: Cable socket 4 | Flat gasket Flat seal made of nitrile rubber | Appliance plug 4 | Appliance plug 3+PE | Circlip Circlip for 2 + PE types
Related Manufacturers: Amphenol | Binder | Neutrik | Souriau | TE Connectivity
电话:400-900-3095
QQ:800152669

STAS 200Family Information

Series Description
  • Connector for motor connections, such as Storen motors
  • For network voltage and control line connections
  • Shake-proof through closure and pull relief

STAS 200产地与重量

Country of origin Germany (DE)
Manufacturer Belden Hirschmann
Gross weight (incl. package) 20.0 Gram
Dimensions (incl. package) 65 x 20 x 17 MM
Customs number 8536699099
UNSPSC (v5.03) 30211816
