LM5101AM/NOPB -

Bridge Driver IC SO-8, LM5101, LM5101AM/NOPB, Texas Instruments

Texas Instruments LM5101AM/NOPB
声明：图片仅供参考，请以实物为准！
制造商产品编号：
LM5101AM/NOPB
仓库库存编号：
173-27-129
技术数据表：
View LM5101AM/NOPB Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

LM5101AM/NOPB技术参数

Source output current 3 A
Output voltage 8...14 V
Package SO-8
Output Voltage max. 14 V
Output voltage min. 8 V

LM5101AM/NOPB产品信息

Supply voltage min. 9 V
Supply voltage max. 14 V
Operating temperature -40...+125 °C
Power supply 9...14 V
Rise time 15 ns
Release time 15 ns
Input logic input
Related Manufacturers: Microchip | NXP | Linear Technology | ST | Maxim
Related Products: Interface IC USB / UART SSOP-28 | Interface IC RS232 SO-16 | Interface IC CAN SO-8 | Bridge Driver IC DIL-8 | Interface IC RS232 DIL-16
Related Categories: Power Management | Amplifiers & Comparators | Logic | Interfaces | Data & Signal Converters
电话:400-900-3095
QQ:800152669

LM5101AM/NOPBFamily Information

  • Drives high-side and low-side N-channel MOSFETs
  • Drives 1000 pF loads with rise and fall times of 15 ns
  • Can be used as a half or full bridge converter or as a synchronous step-down converter.
  • Pin-compatible with HIP2100/HIP2101

LM5101AM/NOPB产地与重量

Country of origin United States (US)
Manufacturer Texas Instruments
Gross weight (incl. package) 1.0 Gram
Dimensions (incl. package) 6 x 5 x 1 MM
Customs number 8542399000
UNSPSC (v5.03) 32101619
